RKC
NEW
Measurement accuracy: ±0.1% of displayed value
Sampling time: 0.01 sec.
11-segment 5 digit LCD display
Front loader communication port
AUTONICS
● Compact, space-saving design with 22.5mm width size
● 50ms high-speed sampling and ±0.3% display accuracy
● Simultaneous heating/cooling and automatic/manual control function
AUTONICS
● 50 ms high-speed sampling rate and ±0.3% display accuracy
● Large LCD display with easy-to-read white PV characters
● Switch between current output and SSR drive output
AUTONICS
● 50 ms high-speed sampling rate and ±0.3% display accuracy
● Simultaneous heating and cooling control function
● Switch between current output and SSR drive output
AUTONICS
● 100 ms high-speed sampling rate and ±0.5% display accuracy
● Switch between relay output and SSR drive output
● Single digital display (switch between PV and SV)
AUTONICS
● 100 ms high-speed sampling rate and ±0.5% display accuracy
● Switch between relay output and SSR drive output
● Dual digital display (PV/SV)
AUTONICS
● High speed sampling of 50ms and ±0.3% display accuracy
● Enable to check control output operation amount by adopting bar graph
● Simultaneous heating/cooling control and automatic/manual control for high performance control
AUTONICS
● Dual-speed PID control
● 2-step auto tuning function
● High display accuracy: ±0.3% of full-scale value
AUTONICS
● Dual-speed PID control
● 2-step auto tuning function
● High display accuracy: ±0.3% of full-scale value
AUTONICS
● Various control output options: relay, SSR drive, current
● 2 independent set points and control outputs for heating and cooling control (T4LP)
● Various sizes (W 48 x H 48, W 48 x H 96, W 72 x H 72, W 96 x H 96 mm)
AUTONICS
● ON/OFF control
● Standard input type: thermistor (NTC) *RTD (Pt100Ω) input models available upon request.
● Temperature range: - Thermistor (NTC): -40.0 to 99.9 °C (-40 to 212 °F) - RTD (Pt100Ω): -99.9 to 99.9 °C (-148 to 212 °F)
AUTONICS
● Standard installation size for refrigeration panels (W 70.3 x H 28.2 mm)
● Various compressor load current capacity: 5A, 16A, 20A
● Various user-friendly functions (defrost sync, real-time clock, alarm, etc.)
AUTONICS
● Remotely monitor current temperature status
● Remotely monitor controller output status
● Available in 3 m, 5 m cable lengths
AUTONICS
● Easy maintenance with detachable body and base terminal
● Power supply and communication with expansion connectors (up to 32 units)
● Parameter configuration with PCs (USB or RS485 communication) : DAQMaster software provided (comprehensive device management software)
AUTONICS
● Multi-channel (4-channel: TM4 / 2-channel: TM2) input and output control
● High-speed sampling cycle (4-channel: 100 ms / 2-channel: 50 ms)
● Module connection and expansion with expansion connectors
AUTONICS
● High performance temperature control at low cost
● Flexible installation in various applications
● Dual-speed PID control
AUTONICS
● Auto-tuning PID temperature control
● PID and ON/OFF control: toggle via external switch
● Deviation indicators (green, red LED) and control output indicator (red LED)
RKC
The maximum of 320-channel temperature control Up to 10 modules can be connected to a single Power/CPU module.
Read More >
RKC
Measurement accuracy: ±0.05°C
Sampling time: 0.1 sec.
Measurement range: 0.000 to 50.000°C (Resolution: 0.001°C)
Max. 2-channel control
Excellent control stability through PFF (Power feedforward)
Plug-in construction
RKC
Measurement accuracy: ±0.1% of displayed value
Sampling time: 0.025 sec.
Max. 2-CH control
Max. 2-point communication
Excellent control stability by PFF (Power Feed Forward)
Plug-in construction
